+12V
GPS
Navico Expansion Port
(Optional)
PWRETHERNETWORKS
NMEA 2000
®
XDCR
+12V
+12V
+12V
+12V
+12V
26 27
www.lowrance.com
Networking & Digitals Gauges
Networking & Digital Gauges
Lowrance NMEA 2000
®
Networking
Lowrance offers a full array of non-proprietary antennae, gauges and sensors for NMEA 2000
®
networking for
onboard systems monitoring. And only Lowrance offers the most choices, the most complete/congurable user
interface for devices monitoring, and waypoint/sonar depth sharing on the network.
NEW LGC-4000 GPS
Receiver Antenna
A mighty new 16-channel NMEA 2000
®
GPS+EGNOS+MSAS antenna scores
high in superior sensitivity for signal
acquisition, with incredible position
accuracy, in a new compact size that’s
easier to ush-mount.
• Works with any NMEA 2000
®
network
for enhanced location accuracy and
improved satellite-signal x with
reduced wandering
• Advanced performance for Lowrance
HDS models with a true update rate of
5 times per second for the most
accurate speed-over-ground readings
• New, compact 3”/75mm diameter
module is just 1.3”/33 mm high and
offers top mounting ease
• Rugged for all marine environments
and fully waterproof
• Spat cone for pole mounting
LMF Multi-Function
Gauges
Lowrance LMF models are NMEA
2000
®
certied digital gauges providing
precision and versatility for real-time
monitoring of engine and boat systems
on the NMEA 2000
®
network. Plus,
they’re backed by the most extensive
and affordable selection of smart
sensors, including Fuel Flow for
optimum fuel management economies.
• Allows building of custom screens with
up to four different data readings in
choice of analog-style graphics or
alpha/numeric styles
• Shows data from engines and other
sensors on 13 customizable screen
types
• Displays up to 16 pages with choice of
static or manual and timer screen
rotation
• Features standard or metric fuel
economy readings when used in
conjunction with EP-60R Fuel Flow
sensor and speed sensor: EP70R
Speed, EP90R Pressure or networked
GPS antenna
Engine Interface Sensors
Cabled sensors for top outboard brands
connects engines to NMEA 2000
®
networks to display engine data.
LMF-400
• 2.5”/6.4 cm 132x132
pixel Film SuperTwist
4-level grayscale display
with superb viewing in
direct sunlight
• Advanced white LED
screen backlighting
• Sealed and waterproof
to IPX-7
• Fits standard 3-3/8”
(86 mm) dia. hole
LMF-200
• 1.4”/3.6 cm 65x65 pixel
Film SuperTwist 4-level
grayscale display with
superb viewing in direct
sunlight
• Advanced white LED
screen backlighting
• Sealed and waterproof
to IPX-7
• Fits standard 2-1/8” (55
mm) dia. hole
EP Electronic
Probe Sensors
Only Lowrance offers the most NMEA
2000
®
sensors for vital boat data
monitoring, each with a built-in “smart
module,” that’s fully programmable for
greater accuracy in data delivery.
EP-60R Fuel Flow
Congurable, for petrol only, one per
engine. Sapphire bearing technology
extends life and increases accuracy
even at low ow. Outputs Fuel Flow, Fuel
Used, Trip Fuel Used and Seasonal Fuel
Used data to the network for fuel
management. NMEA 2000
®
certied.
EP-65R Fluid Level
Compatible with standard U.S. and
European sending units and a range of
uids: fuel; fresh, waste or black water;
live well; and oil. Allows calibration for
more accurate uid level readings for
boats with odd-shaped tanks. NMEA
2000
®
certied.
EP-70R Speed
Paddle wheel for speed and distance
display; NMEA 2000
®
certied.
EP-80R Temperature
Congurable sensor for surface water,
livewell, baitwell, cabin and engine room
temp readings, -20ºC to 80ºC (-4º to
176ºF). NMEA 2000
®
certied.
EP-80R TH Temperature
Congurable surface water temp sensor
for thru-hull installation. NMEA 2000
®
certied.
EP-85R Storage Device
Accumulates and stores real-time engine
data of fuel ow messages for up to
three engines connected to a NMEA
2000
®
network for fuel range
calculations and display. NMEA 2000
®
certication pending.
EP-90R Pressure
Outputs pitot speed or engine pressure
readings – boost, coolant, fuel, engine or
transmission oil. 100 psi max. NMEA
2000
®
certication pending.
Yamaha (late model)
Suzuki (DF Series)
Evinrude (E-TEC)
LGC-4000
Ethernetworks
Advanced, plug-and-play and high-speed ethernet networking, with a choice of
performance module options to take you to the next level of shing success.
LBS-1 Broadband Sounder Module
Making the best sonar even better, Broadband marks sh
targets in, around and through structure, while operating
at high speeds in challenging conditions, perfect for
sounding shallows to extraordinary depths.
For use with a single Lowrance unit, or networked with a
wide choice of compatible Lowrance models using the
NEP-1 Expansion Port. Lowrance Broadband Sounder
also converts any compatible chartplotter into a
shnder/GPS chartplotter combo.
• Phenomenal separation of sh targets from structure,
baitsh, thermoclines, clutter and bottom
• Improved underwater sh-holding structure identication;
channels, rock piles, stump beds, submerged standing
timber, drop-offs and more
• Exceptional sh-nding performance in any water/
weather situation, at all depths and at any speed
• Compatible with all 2007 and later LCX, LMS, X and
GlobalMap
®
chartplotter models with yellow 5-pin
ethernet connector
• Connects to any existing Lowrance transducer:
Skimmer
®
, pod, shoot-thru and bolt-thru hull
• Automatic operation at any frequency selected: 50, 83
and 200 kHz
• Tested sounding depths to 5,000’ / 1,525 m
NEP-1 Ethernet Expansion Port
A plug-and-play hub for high-speed data-sharing of
multiple HDS, LCX, LMS and GlobalMap
®
products
across the onboard network. Waterproof expansion
ports resist corrosive marine environments. Unused
expansion ports capped for future expansion.
• Robust 100-megabit switch for high-speed data
transfer
• Compatible with all HDS models, plus 2007 and later
LCX, LMS, X and GlobalMap
®
models with yellow
5-pin ethernet connector
• Transmits sonar graphing display/control on
GlobalMap
®
and HDS chartplotters when networked
with sonar-equipped Lowrance units
• Rugged and fully waterproof to IPX-7
• Connectivity for up to four compatible head units per
expansion module
• Links with other Expansion Port-1 modules for added/
future expansion
Ethernetworks Cables
Rugged, high-speed, moisture- and solvent-resistant data
cables withstand the toughest onboard marine
environments. For Lowrance models with 5-pin yellow
ethernet connector.
Multi-Station Network
NMEA 2000
®
Network Starter Kit
Here’s how to easily start your own NMEA 2000
®
onboard network, allowing future expansion to
add sensors and displays. NMEA 2000
®
compliant components include two T-connectors,
2-foot cable, 15-foot cable, two terminating
resistors and network power cable.
N2K-EXP-RD-2 124-69
