SKU 45009, 92261 For technical questions, please call 1-800-444-3353 Page 2
Specifications
Operating Pressure 125 PSI (maximum)
Air Inlet and Outlet Size
(ITEM 45009)
3
/
8
inch, 18 NPT
(ITEM 92261)
1
/
2
inch, 20 NPT
Mounting Bracket 2 slots: 0.2 x 0.69 inches; removable
Overall Dimensions 8-
3
/
4
x 4-
5
/
8
x 7-
3
/
8
inches
Weight 2.75 lb.
Filter
Polycarbonate housing; removable;
7
/
8
” ~
15
/
16
” ID x 1” OD x
31
/
32
” (L)
Features
Adjustable pressure;
Pressure Gauge: 0 ~ 200 PSI; 0 ~ 14 Bar;
Bleeder drains
Save This Manual
You will need the manual for the safety warnings and precautions, assembly
instructions, operating and maintenance procedures, parts list and diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep the manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tools, basic safety precautions should always be fol-
lowed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Don’t expose to rain. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not let them
handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit
rust. Always lock up tools and keep out of reach of children.
5. Use the right tool for the job. Do not attempt to force a small tool or attachment to
do the work of a larger industrial tool. There are certain applications for which this
tool was designed. It will do the job better and more safely at the rate for which it was
intended. Do not modify this tool and do not use this tool for a purpose for which it was
not intended.
