driver and passenger seats. Make sure the windshield is
clean and dry to ensure a tight grip.
(1) When the suction on the vehicle mount is placed into
position, (2) press and hold the center button while you
firmly flip the latch down. This will lock the holder in
place.
2. Connect the GPS Receiver
Locate the input/output area on the backside of the
navigation unit, then insert the GPS Receiver, “GPS” letter
side up.
3. Plug the Cigarette Lighter Adapter
1. Introduction
1.1. What is in the Box?
The Navigation System box includes the following items:
Finedrive 400 Navigation Unit
SD Card w/NAVTEQ Mapping Software
GPS Receiver
DC12V In-car Cigarette Lighter Adapter
Vehicle Suction Mount
Stylus Pen
User Guide
1.2. Installation Precaution
Choose a mounting location in your vehicle where this unit will
not distract or otherwise interfere with the driver’s ability to
control the vehicle.
Do not install components in areas which are susceptible to rain,
moisture, direct sunlight, extreme heat or cold, excessive dust,
dirt or humidity.
Use only installation parts and hardware provided with the unit
to ensure proper installation. Using other parts can cause
malfunction and possible damage to your navigation system.
1.3. Hardware Installation
1. Mount the Finedrive 400 in your vehicle
Although the Finedrive 400 can be installed on any glass
surface in your vehicle, we recommend that you install
the unit below the-center of the windshield, between the
