Power Connection
To power Passport, plug the small end of
the SmartCord, (telephone-type
connector) into the modular jack on
Passport’s right side, and plug the lighter
plug adapter into your vehicle’s lighter
socket or accessory socket.
Passport operates on
12 volts DC negative
ground only. The lighter plug provided is a
standard size and will work in most vehicles.
However, some vehicles may require the
enclosed sleeve to ensure a snug fit. If so,
simply slide the sleeve over the SmartCord’s
lighter plug adapter. Of course, your lighter
socket must be clean and properly
connected for proper operation.
Note: depending on your vehicle, the lighter
socket power may either be continuously
on, or it may be switched on and off with
your ignition switch.
Optional power cords
See the Accessories section for details on
our optional Direct-wire SmartCord.
Windshield Mount
Passport’s EasyMount windshield bracket is
designed for unobtrusive and hassle-free
mounting.
1 Depress the adjustment button on the
top of Passport (by the word ESCORT) and
slide the EasyMount bracket into the slot
until it is locked into the position which
best fits the angle of your windshield (there
are four settings available). For extremely
horizontal or extremely sloped windshields,
the EasyMount bracket can be bent.
To ensure that the suction cups adhere to
the windshield firmly, be sure to keep both
your windshield and the suction cups clean.
2 To adjust Passport on your windshield,
use the EasyMount adjustment button
located on the top of the Passport, and slide
Passport forward or backward to obtain a
level horizontal position.
When installed and adjusted properly, the
back top edge of Passport should rest
solidly against your windshield.
Caution!
A few vehicles (including some Porsches)
have windshields with a soft anti-lacerative
coating on the inside surface. Use of
suction cups will permanently mar this
coating. Consult your dealership or the
vehicle owner’s manual to determine if
your windshield has this coating.
User’s Tip
You can leave the EasyMount bracket in
place on your windshield, and easily remove
Passport by pressing the adjustment button
and sliding Passport off the mount. Again,
be sure to position the bracket where it
won’t present a hazard in the event of an
accident. Additional mounts are available.
Mounting Location
WARNING: ESCORT cannot anticipate the
many ways Passport can be mounted. It is
important that you mount Passport where it
will not impair your view nor present
a hazard in case of an accident.
Where to mount Passport
For optimum detection performance, we
recommend the following:
• Using the Windshield Mount, mount your
Passport level, and high enough on your
front windshield to provide a clear view of
the road from the front and rear.
• Mount Passport away from windshield
wipers, other solid objects, and heavily
tinted areas that might obstruct the radar
antenna or laser lens.
6 7
Installation Windshield Mount
