900 IV TRANSMITTER / 999FM TRANSCEIVER CODE LEARNING
Transmitter/Transceiver Code Learning: (Excludes RS901)
Note: All transmitter codes must be learned at time of programming!! The RS900 IV system allows storage of up
to 4 different transmitter codes.
1. Open hood (ground the Gray hood pin wire if no hood pin is installed.)
2. Turn key to the ON position. (Doors will lock if Autolock is programmed)
3. Press Programming button 4 times, then after a few seconds the unit will flash the parking lights 4 times.
4. Press button #1 of the transmitter to be learned. You should get 2 light flashes indication the unit is waiting for a 2
nd
code, then press button #1 of a second transmitter, the unit will flash 3 times indicating its waiting for the 3
rd
code and
lights will flash 4 times for 4
th
code. If all 4 codes are learned, the unit will automatically exit code learning mode,
otherwise turn key off and close hood. (See Diagram Below)
IGN
OFF
WAIT FOR
4 FLASHES
PRESS 4X's
FLASH 2, 3, or 4 X's
START
C
RIME
S
TOPPER
(GRAY WIRE GROUNDED)
RS999FM
RS900 IV
IGN
OFF
