TABLE OF CONTENTS
Pre-Installation Considerations…………...……...………………………………………………………………Front Cover
Cautions & Warnings…….…………..….……..…..……………………………………………………………….…..……2
Wiring……..…………………………....……………………………………………………………………………….…….3-5
Wiring High-Current Connector…….………………...………………………………………………………………….....5-6
Power Door Lock Wiring…………...………………...…………………………………………………………………......7-8
Smart Tachless, Tach Reference & Tach Finder Modes…………………..…..………...…...…………………..….…9-10
Transmitter Programming……………………….…………………….……………..………...………………………....…11
2 Vehicle Operation.……………………………….……………………………………...…………………….……………11
Option Programming………..……………………….…………………………………...……………..………..……..…12-13
Troubleshooting “Before You Call” Section……………..…………………………..………………….……..….……….14
System Diagram…………………………………………………….……………………………………………….….……15
INSTALLATION CAUTIONS & WARNINGS
**FOR SAFETY REASONS, DO NOT INSTALL THE RS-850 in vehicles with MANUAL TRANSMISSIONS.** If
accidentally left in gear, a remote started vehicle could become a self-propelled threat to life and property.
WARNING: This system does NOT have engine over-rev protection. Make certain vehicle throttle linkage operates
properly and does not stick. A stuck throttle will cause severe engine damage
DO NOT extend the RS-850 Ignition harness length. Mount the module so that main harness reaches all ignition switch
wiring. Extending these wires could result in poor performance.
DO NOT route any wiring that may become entangled with brake, and gas pedals, steering column, or any other moving
parts in the vehicle.
DO NOT exceed the rated output current of any circuit on the Remote start module. Failure to observe this warning will
result in damage to the unit not covered under warranty.
DO NOT remote start the vehicle in a closed garage. Make sure that the garage door is open or there is adequate
ventilation. Failure to observe this rule could result in injury or death from poisonous Carbon Monoxide fumes.
2
