OPTION PROGRAMMING
* = DEFAULT
Option
#
Option Description Option Values Tap Brake
Pedal
Push Start
Button
1 NOT USED NOT USED
2 NOT USED NOT USED
3 NOT USED NOT USED
4 Engine Monitoring Tach (Engine RPM) or Tachless
Mode
Tach
(Engine RPM)
Tachless*
5 Remote Start Engine Run
Time
24 or 36 Minutes 36 Min. 24 Min*.
6 Smart Tachless Voltage
Adjust 80-100% (Only when
option #4 is set to Tachless)
Tap brake to Decrease 1% or Push
Start Button to Increase by 1%
-1% +1%
7 Option reset Reset to
Default
OPTIONS DESCRIPTIONS:
OPTIONS #1-3 ARE NOT USED.
4. Engine Monitoring:
This option sets how the system monitors your engine. You can program either for Tach mode in which the unit uses a
Tach signal (RPM) or for Tachless mode that monitors voltage level. See page 7 for more information.
5. Remote Start Run Time:
This option controls the engine run time for remote start. You can select either 24 or 36 minutes.
6. Smart Tachless Voltage Adjustment:
This option controls the voltage reference point when using Smart Tachless mode. Either tapping the brake or pressing
the Start button on the remote raises or lowers the reference level in 1% increments from 80%-%100. The default
voltage setting is 90%, which works well for most vehicles. See page 6 for additional Smart Tachless mode information.
7. Option Reset:
This option allows you to restore all programmable options to factory default values. Go to the 7
th
option and press
the Start Button on the remote. The unit will flash the lights 2 times and all values will be reset to Default.
10
