AXIS P3364–LV Network Camera
Technical Specifications
Function/group
Item
Specications
Flicker: EN61000-3-3
Immunity: EN55024, EN61000-6-1, EN61000-6-2
Safety: : IEC/EN/UL 60950-1
FCC:
FCC Part 15, Subpart B, Class B demonstrated by compliance with EN55022 (CISPR 22)
Japan: VCCI-2008, Class B, ITE • C-tick AS/NZS CISPR 22, demonstrated by compliance
with EN55022 (CISPR 22)
Canada: ICES-003 Canadian ICES-003, Class B digital, demonstrated by compliance
with EN55022 (CISPR 22)
Korea:
Emission: KN22
Immunity: KN24
Environmental: IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-27, IEC
60068-2-64, IEC 60068-2-78, IEC 62262 IK10
IR: EN-62471
Dimensions
(HxWxD)
97 x 148 x 148 mm (3.82 x 5.83 x 5.83")
Weight
670 g (1.5 lb.)
Included
accessories
Installation Guide, recording software and User Manual, Windows decoder 1-user license
Connector kit
Video
management
software (not
included)
AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’
Application Development Partners available on www.axis.com/techsup/software
Optional
accessories
AXIS Illuminators
AXIS T91A brackets
IP51-rated drop-ceiling mount kit with transparent or smoked cover
Pendant adapter kit
Mounting bracket
Languages
German, French, Spanish, Italian, Russian, Simplied Chinese, Japanese, Korean,
Portuguese
Warranty
Axis 3-year warranty and AXIS Extended Warranty option, see www.axis.com/warranty
Connectors
I/O Connector
4-pin terminal block
1 2 3 4
For an example diagram, see Connection Diagrams on page 67.
Function Pin Notes
Specications
0 V DC (-)
1
0 V DC
DC output
2
Can be used to power auxiliary equipment.
Note: This pin can only be used as power out.
3.3 V DC
Max load = 50 mA
