Shoulder belt height adjustment
(Except for rear center seat)
The shoulder belt anchor height should be ad-
justed to the position best suited for you. (See
“Precautions on seat belt usage” earlier in this
section.) To lower, pull the release button, and
then move the shoulder belt anchor to the
desired position, so that the belt passes over the
shoulder. Release the adjustment button to lock
the shoulder belt anchor into position.
To raise, move the adjuster up to the desired
position without pushing the button.
WARNING
¼ After adjustment, release the adjust-
ment button and try to move the
shoulder belt down to make sure it is
securely fixed in position.
¼ The shoulder belt anchor height
should be adjusted to the position
best for you. Failure to do so may
reduce the effectiveness of the entire
restraint system and increase the
chance or severity of injury in an
accident.
Seat belt hook
When folding down the rear seat, hook the rear
seat belt at the belt hook.
SPA0739 SSS0231
1-28 Seats, restraints and supplemental air bag systems
੬ 04.4.5/Z50-D/V5.0 ੭
