C–8 Maintenance and Service Guide
Screw Listing
Phillips M2.5×8.0 Screw Locations
Table C-4
Phillips PM2.5×8.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 26 8.0 mm 2.5 mm 5.0 mm
Where used:
1 Two screws that secure the optical drive to the notebook: one in the memory
module/Mini PCI compartment (documented in Section 5.7) and one in the
battery bay (documented in Section 5.11)
2 One screw that secures the keyboard to the notebook in the heat sink
compartment (documented in Section 5.8)
mm
