5.15 Processor
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
❏ Optical drive (Section 5.7)
❏ Keyboard (Section 5.8)
❏ Keyboard cover (Section 5.9)
❏ Display assembly (Section 5.10)
❏ Top cover (Section 5.11)
❏ System board (Section 5.12)
❏ Heat sink (Section 5.14)
Spare Part Number Information
For use with all models
Intel Pentium 4 with 800-MHz FSB and Hyper-Threading
Technology (HT Technology)
3.2-GHz
Intel Pentium 4 with 800-MHz FSB
3.4-GHz
3.2-GHz
3.0-GHz
2.8-GHz
344890-001
370958-001
344889-001
344888-001
344887-001
For use with HP zd7000 models
Intel Pentium 4 with 800-MHz FSB and Hyper-Threading
Technology (HT Technology) Extreme Edition
3.2-GHz
Intel Pentium 4 with 533-MHz FSB and HT Technology
3.06-GHz
Mobile Intel Pentium 4 with 533-MHz FSB and
HT Technology
3.2-GHz
3.06-GHz
2.8-GHz
Intel Pentium 4 with 533-MHz FSB
2.8-GHz
2.66-GHz
361672-001
344886-001
356962-001
356673-001
356672-001
344885-001
344884-001
