HP Jetdirect EIO Control Panel Menus 37
ENWW
Classic Control Panel
Classic control panels can typically display
two lines of 16 characters each.
As described in Table C-1, the HP Jetdirect
EIO control panel menu allows you to enable
or disable network protocols, and configure
selected network parameters. On the control
panel display, an asterisk (*) is used to
identify the selected value.
Table C-1. EIO Classic Control Panel Menu (1 of 3)
Menu Item Description
CFG NETWORK= Selects whether or not you want to access the Jetdirect
menu.
● NO (default): Bypass the HP Jetdirect menu.
● YES: Access the HP Jetdirect menu. You must
change this to YES* each time you want to access
the menu.
TCP/IP=
IPX/SPX=
DLC/LLC=
ATALK/ETALK=
Identifies whether the protocol stack is enabled or
disabled.
● ON (default). The protocol is enabled.
● OFF: The protocol is disabled.
