www.SCEPTRE.com
SCEPTRE POWER BOOST User Manual
Specification
SUBJECT
CONTENT
Model Name
SS1000
Capacity
4200 mAH
Working Voltage
13.2V~14.2V
Max. Continuous Output
140A, Anderson Connecter
10 Second Output
240A, Anderson Connecter
USB Output
1000mA + 2100mA (max: 3000mA)
Cigar Socket Output
< 20A (Limited by 20A Fuse)
AC-DC Adapter
100 – 240VAC, 50/60 Hz, 0.8A
DC Input Jack: 15V/2A.
(Max. Voltage/Current: 16.5V/2A)
Charge Cut off Voltage
14.7 V
Power Level Indicator
R: Red LED
G: Green LED
Y: Yellow LED
G - Flashing : >14.8V (Protection)
RGY ON : 13.0V ~ 14.8V
RY ON : 12.0V ~ 13.0V
R ON : 11.5V ~ 12.0V
R – Flashing : 11.0V ~ 11.5V (Protection)
No Response : < 11.0V
High Voltage Protection
14.7V Stop Charging (14.5V tiny current charge)
Low Voltage Protection
10.7V
(Power Level Indicator： Red LED Flashing)
Warning Sound “Beep”
Charging Without Turn On The Main Switch
(G-Flashing)
Over-Voltage Charging (G-Flashing)
Over-Current Charging (Y-Flashing)
Low Power Indication
(USB Output and LED Lighting Turn Off)
Battery Cell
Lithium Iron Phosphate Battery
Product Weight
2.76 lb (Without Accessory)
Product Dimension
7.48” (L) × 3.54” (W) × 5.12” (H)
Operation Temperature
-22 °F to 140 °F
Operation Humidity
< 80% RH
Certification
FCC, CE, UN38.3
Warranty
Limited Parts & Labor 1 Year
