118
SPECIFICATIONS
* Based on EU Directive 76/432/EC
SPORTSMAN 800 EFI
Maximum Weight Capacity 515 lbs. (234 kg)
Fuel Capacity 4.13 gal. (15.6 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 3.6 qts. (3.4 l)
Rear Gearcase Oil Capacity 5 oz. (150 ml)
Demand Drive Fluid Capacity 9 oz. (265 ml)
Transmission Oil Capacity 15 oz. (450 ml)
Front Rack/Storage Box Capacity 100 lbs. (45 kg)
Rear Rack Capacity 200 lbs. (91 kg)
Receiver Hitch Tongue Capacity 150 lbs. (68 kg) (Rear rack capacity and
tongue weight not to exceed 200 lbs./91 kg)
Hitch Towing Rating 1500 lbs. (680.4 kg)
Unbraked Trailer Towing Capacity* 1914 lbs. (868 kg)
Overall Length 83 in. (211 cm)
Overall Width 48 in. (122 cm)
Overall Height 48 in. (122 cm)
Wheelbase 50.75 in. (128.9 cm)
Ground Clearance 11.25 in. (28.5 cm)
Dry Weight 770 lbs. (349 kg) (with cast wheels)
780 lbs. (354 kg) (with steel wheels)
Minimum Turning Radius 76 in. (193 cm) unloaded
Engine EH0760LE
Displacement 760 cc
Bore x Stroke 80 x 76
Alternator Output 500 Watts @ 3000 rpm
Compression Ratio 10:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System ECU
Ignition Timing 8 BTDC @ 2000 RPM
Spark Plug / Gap RC7YC / .035 in. (0.9 mm)
Lubrication System Pressurized Wet Sump
Driving System Type Automatic PVT (Polaris Variable Transmis-
sion)
Front Suspension MacPherson strut with 8.2" (21 cm) travel
Rear Suspension Progressive rate with 9.5" (24 cm) travel
