transmitter to operate your system for the purpose of stealing your vehicle or its
contents.
Additionally, in normal operation, every time the ignition switch is turned "on",
the LED Status Indicator will flash and pause for ten seconds, the number of flashes
between each pause being equal to the number of transmitters encoded to operate
your system. For example: two flashes and a pause indicate that only two
transmitters are coded to operate your system. In the event the system alerts you
to a recent transmitter addition, you can now immediately reprogram your
transmitters, effectively erasing any unauthorized transmitters.
Transmitter Code Jumping
TM
: The transmitter sends a digitally coded signal
to the security system. The transmitter and security system will advance to another
code to use for the transmission. With each use, this digital signal changes. This
Code Jumping
TM
feature prevents a thief from using a "code grabber" device to
record and play back a transmission for the purpose of disarming your vehicle
security system.
Page - 5
For the first 48 hours after any transmitter is encoded to operate the
system, every time the ignition switch is turned "on", the siren will chirp
rapidly for two seconds, and the LED Status Light will flash for 90 seconds.
Transmitter Operations
Also see pages 26 and 38-39
LED Light- Illuminates
when a button is pressed.
Page - 6
K K
K K
K -
9
Large Transmitter Button-
Pressing and releasing this button will arm and disarm the security system. If the optional
doorlock interface is installed, the doors will lock upon arming, and unlock upon disarming
(however, if the system is in a triggered condition, disarming will not unlock the doors).
Pressing and holding this button for 3 seconds will "Panic" the system- which will sound the
siren or horn, flash the exterior and interior lights and also lock the doors.
Small Right Transmitter
Button- If this button is
held for 3 seconds, the se-
curity system will activate
the 2nd channel output
(typically used for trunk
release). If this button is
pressed twice, the system
will arm or disarm without
audible chirps.
Small Left Transmitter
Button- Pressing the small
left transmitter button for
2.5 seconds activates the 3rd
channel output, which may
be used to operate optional
devices. If an optional aux-
iliary sensor is part of the
system, pressing this button
within 4 seconds after arm-
ing the system will turn the
sensor off.
Arming The System Using The Transmitter
Arming The Security System Using The Transmitter: The security system
can always be armed from the transmitter provided the ignition key is “off” and the
system is disarmed and not in the Valet Mode. To arm the system, after you exit
the vehicle and close all of the doors, simply press and release the large transmitter
button once. Instantly the parking lights will flash once, the siren will chirp once and
the LED Status Indicator will begin to flash confirming that the system is armed.
Further, the doors will lock and the starter interrupt relay will engage to prevent any
attempt to start the vehicle. Your security system is now fully armed, and is ready
to respond if an intrusion attempt is detected.
Arming Bypass: Upon arming, if any sensing circuit is inoperable, that circuit
will be bypassed. For example, if the trunk is left open, you can still arm the system
with the transmitter. The bypassed circuit will automatically be reinstated for
protection 5 seconds after the circuit becomes operative, i.e., when the trunk is
closed. When a triggered circuit is in a bypassed state, all other operating circuits
will be protected normally.
Sensor By-Pass: Your security system provides you with the convenience of
temporarily deactivating any optional auxiliary sensor without affecting other
Page - 7
trigger circuits. To deactivate the sensor, simply press and release the small left
transmitter button within 4 seconds after pressing the large transmitter button when
arming the system. You will hear a second siren chirp confirming that the security
system has armed without the sensor protecting the vehicle. The next time you arm
the security system, the system will reset to its normal condition, and the sensor will
again be part of your protection.
Passively Arming The System
Passively Arming The Security System Using Last Door Arming: You can
also pre-select your security system to automatically arm and lock the doors when
the vehicle's last door is closed. The moment the last door closes the siren (or horn,
if used) will chirp once, the parking lights will flash once and the LED Status
Indicator will begin to flash rapidly. Thirty seconds later the siren will chirp again,
the doors will lock (provided that the Passive Lock feature has been chosen) and the
LED Status Indicator will slow to a steady flash, confirming that the security system
is fully armed. If a point of entry is reopened before the single siren chirp at 30
seconds, the passive arming process stops and will reset to start over when the point
of entry is re-closed.
Automatic Last Door Arming offers a high level of security, since you do not
have to remember to arm the security system every time you leave the vehicle.
