Feature #18: Pulsed Horn / Steady Siren Output
(Factory Setting Steady Siren (OFF)
Feature Turned On: This Feature allows the use of the vehicle's horn in place of
the electronic siren for the audible output of the security system. When configured
for use with a horn, this output pulses for 10 seconds, then pauses for 5 seconds,
repeating this cycle for the duration of the activated alarm period. This prevents
the horn from overheating, thereby ensuring a maximum useful life to the vehicle
owner.
Feature Turned Off: The output is a continuous, steady output which the elec-
tronic siren requires. The siren features six different siren tones, which change
every 5 seconds.
Feature #19: Loud / Soft Pulsed Horn Chirps (Factory Setting Loud (ON)
Feature Turned On: 12 Millisecond Confirmation Honks.
Feature Turned Off: 8 Millisecond Confirmation Honks.
If your security system is configured to use the vehicle's horn, this Feature allows
a degree of compensation for the variance which is found in the length of the pulse
required to honk the horn in a satisfactory manner.
Page - 36
Feature #20: Total Closure Lock Output (Factory Setting OFF)
Feature Turned On: 28 Second Doorlock Output.
Feature Turned Off: .8 Second Doorlock Output.
If the vehicle is so equipped, this Feature allows the installer to take advantage of
a preexisting Total Closure System.
Feature #21: Remote-Activated Anti-Carjacking Protection
(Factory Setting OFF)
Feature Turned On: Anti-Carjacking Protection Feature Activated By 3rd
Channel Output. This Feature allows remote activation of the Anti-Carjacking
Feature. If this Feature is turned ON, pressing the Small Left Button on the trans-
mitter for 3 seconds will activate the Anti-Carjacking Feature, but
only when the
ignition switch is "on". This Feature may be activated regardless of the setting of
Features #1 and #2 (Ignition and Door Activated Anti-Carjacking Protection).
Feature Turned Off: 3rd Channel Will Not Operate Anti-Carjacking.
Feature #22: One / Two Button Arming / Disarming
(Factory Setting One Button (ON)
Feature Turned On: One Button Arming / Disarming. This Feature controls
how the transmitter operates the security system. If this Feature is turned ON, the
transmitter's Large Center Button will alternate arming and disarming the system
Page - 37
with each press of the button. This type of operation is also described as a "single
button toggle" for the arming and disarming of the system.
Feature Turned Off: Two Button Arming / Disarming. Having this Feature set
to the OFF setting causes the system to operate in a "dedicated button for arming
and dedicated button for disarming" fashion. This Feature's "Two Button" setting
may be used with the standard 3-button transmitter; when configured in this fashion
the large center button arms the system, and the small right button disarms the
system. Pressing the small right button operates trunk release; pressing the large
center button
and small right button together operates the 3rd channel output.
Page - 38
Enhanced "Panic" operation: Having feature #22 configured
for "Two Button Arming / Disarming" enhances the "Panic"
feature's operation; using the "arm" button activates "Panic" with
an armed system, locking the doors, and using "disarm" button
results in "Panic" with a disarmed system and unlocked doors.
Page - 39
Optional Transmitter Operations
K K
K K
K -
9
K9-5Classic 302MHz w/Red LED (#109-01)
Feature #22 configured for "Two Button Arming / Disarming" with supplied
transmitter
Arms system, and engages
"panic" with system armed
Operates
3rd channel
output
Disarms
system, and
engages
"panic"
with
system
disarmed
Operates
2nd channel
output
