Assembly
9
7/16 x 1-1/4” bol
t
Jac
k
7/16” n
y
loc nu
t
A-frame tow ba
r
Axle suppor
t
Axle gusse
t
Torsion axle
3/8” Class G nut
3/8 x 1-1/4”
bolts
Step Two: Attach the jack to the A-frame tow bar.
1. Attach the jack to the A-frame
tow bar with (4) 7/16 x 1-1/4”
bolts and (4) 7/16” nyloc nuts.
2. Tighten the bolts to 60 ft-
lbs.
Step Three: Build the axle assembly.
Attach the torsion axles to the axle gusset and axle supports using (12) 3/8 x 1-1/4” bolts
and (12) 3/8” Class G nuts. Leave bolts loose until next step.
