Insert mechanical key ; into the driver’s
door lock.
X
Turn mechanical key ; clockwise to
position 1.
The driver’s door is locked.
X
Turn mechanical key ; back and remove
it from the driver’s door lock.
i
This procedure does not arm the anti-
theft alarm system, nor does it lock the fuel
filler flap.
Manually unlocking the gear selector
lever
If the vehicle’s electrical system is
malfunctioning, the gear selector lever could
remain locked in park position P. In this case
the gear selector lever can be unlocked
manually, e.g. to tow the vehicle.
X
Engage the parking brake.
!
Do not use sharp objects to loosen the
gear selector lever cover in the center
console, as this could damage the gear
selector lever cover or the center console.
X
Insert a flat, blunt object into the left edge
of gear selector lever cover : at the
positions indicated by the arrows.
X
Loosen gear selector lever cover : using
this object.
X
Pull gear selector lever cover : out and
remove.
X
Simultaneously push down release ; and
move the gear selector lever out of park
position P.
The gear selector lever is unlocked.
i
The gear selector lever is locked again as
soon as you move it back to park position
P.
Fuel filler flap
G
Warning!
Avoid contact with the vehicle walls as they
may contain sharp edges. Otherwise, you
could injure yourself while releasing the fuel
filler flap.
In case the central locking system does not
release the fuel filler flap, you can open it
manually.
The fuel filler flap release is located on the
passenger side in the trunk behind the side
trim panel.
X
Open the trunk (Y page 71).
X
Remove side trim panel.
i
Removing the side trim panel is a
demanding process. We recommend that
you contact Roadside Assistance
(Y page 166) if you do not feel to have the
ability to perform this process.
Unlocking/locking manually
263
