8-37
Maintenance and Care
Owner Maintenance
Form No. 8R09-EA-02G
Your vehicle’s electrical system is
protected by fuses.
If any lights, accessories, or controls don’t
work, inspect the appropriate circuit
protector. If a fuse has blown, the inside
element will be melted.
If the same fuse blows again, avoid using
that system and consult an Authorized
Mazda Dealer as soon as possible.
▼
Fuse Replacement
If the electrical system doesn’t work, first
inspect fuses on the driver’s side.
1. Turn off the ignition switch and other
switches.
2. Open the fuse panel cover.
3. Pull the fuse straight out with the fuse
puller provided on the fuse panel.
4. Inspect it and replace if it’s blown.
5. Push in a new fuse of the same rating,
and make sure it fits tightly. If it
doesn’t, have an Authorized Mazda
Dealer install it.
If you have no spare fuses, borrow one
of the same rating from a circuit not
essential to vehicle operation, such as
the RADIO circuit.
Fuses
Fuse panel cover
Always replace a fuse with one of the
same rating. Otherwise you may
damage the electric system.
Fuse puller
Normal Blown
CAUTION
