Black plate (105,1)
Manual opening/closing
To open the window to the desired
position, lightly hold down the switch.
To close the window to the desired
position, lightly pull up the switch.
Open
Close
Master control switches
Open
Close
Front/rear passenger switch
Auto-opening/closing
To fully open the window automatically,
press the switch completely down.
To fully close the window automatically,
pull the switch completely up.
To stop the window partway, pull or press
the switch in the opposite direction and
then release it.
NOTE
If the battery was disconnected during
vehicle maintenance, or for other
reasons such as a switch continues to be
operated after the window is fully open/
close, the windows will not fully open
and close automatically. Re-
initialization of the automatic function
on each passenger window cannot be
performed using the master control
switches. Carry out the following
procedure on each door switch to
resume operation:
1. Turn the ignition switch to the ON
position.
2. Press the switch and fully open the
window.
3. Pull up the switch to fully close the
window and continue holding the
switch for about 2 seconds after the
window fully closed.
After the system has been re-initialized,
each passenger window can be fully
opened or closed automatically using
the master control switches.
Two-step down function
With the window completely closed, press
the switch lightly and the window will
open and stop about 3 cm (1 in) from the
top.
If you continue to press and hold the
switch, the window will resume opening
all the way.
Knowing Your Mazda
Doors and Locks
3-35
