GM V6 90 Degree Automobile Parts User Manual



iii
ENGINE APPLICATION MANUAL GM Powertrain
Gasoline 4.3L V6 90 Degree Revised: 08/15/2000
Contact:Luis Nespolo - (248) 857-1558 Printed: 8/15/00
PREFACE
This document will assist the reader in the application of the 4.3L V6 90 Degree Engine to the vehicle.
It gives an overview of the engine, its features, as well as focus on the systems, subsystems and
attachments that interface between the engine and the vehicle.
The performance of the 4.3L V6 90 Degree Engine is dependent on the design and processing of the
interface systems and their components.
Definitions:
The number between bracket shows the Specification level.
VTS: Vehicle Technical Specification. Level (1) SSTS.
Powertrain SSTS: Powertrain Subsystem Technical Specification. Level (2) SSTS.
Composed of Engine, Transmission and Controls, Similar to the other NAO Major Technical
Subsystems, like Electrical, HVAC, Chassis, Body, etc.
Engine SSTS: Engine Subsystem Technical Specification. Level (3) SSTS.
Transmission SSTS: Transmission Subsystem Technical Specification. Level (3) SSTS.
Controls SSTS: Controls Subsystem Technical Specification. Level (3) SSTS.
Cylinder Head SSTS: Cylinder Head Subsystem Technical Specification. Level (4) SSTS.
Piston CTS: Piston Component Technical Specification. Level (5) SSTS.
ACE: Assistant Chief Engineer, AE: Application Engineer, DRE: Design Release Engineer, PTVSE:
Powertrain Vehicle System Engineer.
The Word Subsystem is used in this context to indicate that a System Level (2) is part of a major System
Level (1).
The diagram 1.1 - I shows the scope of this specification with a dot line around the subsystems in which
it place precedence.
Diagram 1.1-I Powertrain SSTS scope of work
