15
LED / VALET SWITCH MOUNTING
LED: The LED is used as a System Status Indicator and it will also FLASH for use as security deterrent when
the Alarm System is Armed.
VALET SWITCH: Mount the Valet Switch (push-button) on dash or other accessible location. It is REQUIRED
for Emergency Disarm, Programming and entering Valet Mode (See pg 13 for Valet Mode).
VALET / PROGRAM SWITCH
STATUS LED
WIRING: SHOCK SENSOR
4 PIN SENSOR PLUG/HARNESS (RED):
GREEN Wire: Negative Trigger.
WHITE Wire: Negative Warn-A-Way.
BLACK Wire: Sensor Ground.
RED Wire: Sensor 12V Power.
SHOCK SENSOR: The sensor supplied with
this system does not require any additional
wiring. Simply mount the sensor in a suitable
location, plug it in, and adjust the sensitivity.
SENSOR ADJUSTMENT
Clockwise = Higher Sensitivity
Counter Clockwise = Lower Sensitivity
