INSTALLATION
Where to Mount Your Unit
You will get optimum performance from your
ESD-9230 WX if you mount it at a point
approximately in the center of the vehicle,
as low as possible on the front windshield
without obstructing the unit's view of the
road either to the front or rear. You can also
mount it directly on the dashboard.
The unit's lenses must not be blocked and
the LaserEye
®
should have a clear view out
the back window to allow 360° detection.
Radar and laser signals pass through glass
but not through other materials and objects.
Objects that can block or weaken incoming
signals include:
windshield wiper blades
mirrored sun screens
dark tinting at the top of the
windshield
heated windshields currently available
on some vehicles (Instaclear for Ford,
®
Electriclear for GM,
®
consult your
dealer to see if you have this option)
2
1
INSTALLATION
5. To adjust the angle if necessary,
gently push or pull on the bracket
to bend it. DO NOT use the
detector to bend the bracket.
6. Plug the power cord into the detector.
7. Plug the cigarette lighter adapter on
the power cord into your vehicle's
cigarette lighter.
8. You can temporarily remove the
detector whenever you wish by
sliding it off of the bracket.
Windshield Mounting
1. Attach the rubber cups to the bracket.
2. Make sure the rubber cups and
your windshield are clean.
3. Push the bracket firmly onto
the windshield.
4. Attach the detector to the bracket.
Check the angle of the unit.
U
L
T
R
A
Windshield mounting
Dashboard mounting
Instaclear for Ford
®
is a registered trademark of Ford Motor Company, Inc.
Electriclear for GM
®
is a registered trademark of General Motors Corporation.
