4
PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger
the alarm in case of emergency.
1. Press and hold the
button on the transmitter for 3 seconds. The
alarm will immediately sound.
2. To stop the alarm, press and hold the
button for 3 seconds on the
transmitter, the panic mode will be turned off immediately.
3. If the button is not pressed, the alarm will automatically stop after 30
seconds.
TRIGGER THE SYSTEM: (OPTIONAL) If alarm option is installed.
When armed, your vehicle is protected as follows:
1. Light impacts will trigger the warn-away signal. A long chirp from siren
/horn.
2. Heavy impacts / Doors open / Hood open / Trunk open / Turning on the
ignition switch- All will trigger the programmed sequence.
The starter disable relay (if installed) prevents the vehicle’s starter from
cranking. The siren or horn and parking lights will turn on to alert of an
intrusion for 30 seconds. Then the siren or horn will stop and automatically
reset and re-arm. If any the sensors or detectors are still active, the alarm
system will sound a maximum of six-30 second cycles.
ANTI CAR-JACKING: (OPTIONAL) If alarm option is installed.
Warning: If you don't need the car jacking function in this alarm system, be
sure to set car jacking feature “OFF”. This system is default setting Car-
jacking “OFF”.
1. TRANSMITTER ACTIVATE THE CAR JACKING:
Press and hold
+ button on the transmitter for 1 second while the
vehicle’s ignition is ON. The parking light will turns on for 1.5” seconds
to indicate car jacking activated.
2. DOOR SWITCH ACTIVATE CAR JACKING:
1. Turn the ignition switch to “ON” position, the system is armed.
2. Once the system is armed, if you are forced from the vehicle, the system
will active the car jacking trigger when the door is opened and closed
while the ignition is “ON”.
TRIGGER THE CAR JACK MODE:
3-timer circuits will function as follows:
First timer:
a. 50 seconds after the system has been triggered. The siren or horn will
start chirping for 15 seconds.
b. During this 15 seconds period of chirping, you will be alerting to push
the valet switch once to turn off the car-jacking feature.
c. If not, it will enter second timer car jacking.
Second timer:
65 seconds after the system has beer triggered. The siren or horn starts
alarming and the parking light starts flashing.
Third timer:
90 seconds after the system has been triggered
a. The siren or horn will still be alarming and the parking light flashing.
b. The starter disable will activate to prevent the vehicle from starting.
c. It will remain active until the vehicle's battery power exhausted.
OVERRIDE THE SYSTEM TO TURN OFF CAR JACKING:
Turn the ignition switch from OFF to ON, and within 10 seconds push
valet switch. The siren or horn will stop and the system will be disarmed
