SETS OPTION 1 – AUTO-LOCK & UNLOCK ENABLED- The doors will lock when
the key is turned on and unlock the when the key is turned off.
SETS OPTION 2 – AUTO LOCK ONLY ENABLED- The doors will lock when the key
is turned on but will not unlock when te key is turned off.
SETS OPTION 3 – AUTO LOCK DISABLED- The doors will not lock or unlock
when the key is turned on or off. (DEFAULT)
SETS OPTION 1 – HORN DISABLED- The HORN and HORN and will activate with
Panic and Car Finder Mode only.
1 CHIRP
1 CHIRP
2 CHIRP
3 CHIRP
SYSTEM PROGRAMMING - Menu 1
PAGE 16
INSTALL MANUAL
PROGRAM MODE
CHANGE SETTING 1 -
GOTO SETTING 2 - PRESS & RELEASE THE VALET SWITCH
PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
SETTING 1- IGNITION AUTO-LOCKS
THE HORN WILL CHIRP 1 TIME WHEN SETTING 1 IS SELECTED
1 CHIRP
PRESS
1 TIME
2 CHIRPS
SETS OPTION 2 – HORN OUTPUT- The HORN and the HORN* (alarm models)
output will activate for all functions. (DEFAULT)
SETS OPTION 1 – DOUBLE UNLOCK & SINGLE LOCK PULSE- The system will
provide 2 unlock pulses w/unlock and 1 lock pulse w/lock.
1 CHIRP
SETS OPTION 2 - DOUBLE LOCK & SINGLE UNLOCK PULSE- The system will
provide 2 lock pulses and 2 unlock pulses.
1X
CHANGE SETTING 2 -
GOTO SETTING 3 - PRESS & RELEASE THE VALET SWITCH
PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
SETTING 2-HORN OUTPUT
THE HORN WILL CHIRP 2 TIMES WHEN SETTING 2 IS SELECTED
2 CHIRPS
PRESS
1 TIME
2X
SETTING 3-DOOR LOCK PULSES
THE HORN WILL CHIRP 3 TIMES WHEN SETTING 3 IS SELECTED
3 CHIRPS
PRESS
1 TIME
3X
CHANGE SETTING 3 -
GOTO SETTING 4 - PRESS & RELEASE THE VALET SWITCH
PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
2 CHIRPS
SETS OPTION 3 – NORMAL OPERATION- The system will pulse once for lock
and once for unlock. (DEFAULT)
3 CHIRPS
CON'T ON NEXT PAGE
ENTERING PROGRAM MODE 1
ON/OFF - ON/OFF - ON
(Leaving the key ON)
IGNITION KEY
Press and release 1 time
PROGRAM SWITCH
1 CHIRP
Confirming
Program Mode
HORN CHIRP
Press LOCK
Button to
Select Menu 1
REMOTE BUTTON
72 SERIES
SYSTEM PROGRAMMING - Menu 1
SYSTEM PROGRAMMING - Menu 1
PAGE 17
INSTALL MANUAL
PROGRAM MODE
SETS OPTION 1 - SHORT PULSES- The output for lock and unlock is .25sec. Helps
prevent windows from rolling up/down on some vehicles..
SETS OPTION 2 – LONG PULSES- The output for lock and unlock is 3 seconds.
Used to activate vacuum door lock systems.
SETS OPTION 3 – NORMAL PULSES- The output for lock and unlock is .75sec.
Used for most vehicles. (DEFAULT)
CON'T FROM PREVIOUS PAGE
CHANGE SETTING 4 -
GOTO SETTING 5 - PRESS & RELEASE THE VALET SWITCH
PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
SETTING 4- DOOR LOCK TIMING
THE HORN WILL CHIRP 4 TIMES WHEN SETTING 4 IS SELECTED
4 CHIRPS
PRESS
1 TIME
4X
1 CHIRP
2 CHIRPS
3 CHIRPS
CHANGE SETTING 5 -
GOTO SETTING 6 - PRESS & RELEASE THE VALET SWITCH
PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
SETTING 5- AUX OUTPUT 1
THE HORN WILL CHIRP 5 TIMES WHEN SETTING 5 IS SELECTED
5 CHIRPS
PRESS
1 TIME
5X
1 CHIRP
2 CHIRPS
3 CHIRPS
CHANGE SETTING 6 -
GOTO SETTING 7 - PRESS & RELEASE THE VALET SWITCH
PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
SETTING 6- AUX CHANNEL 2
THE HORN WILL CHIRP 6 TIMES WHEN SETTING 6 IS SELECTED
6 CHIRPS
PRESS
1 TIME
6X
1 CHIRP
2 CHIRPS
3 CHIRPS
SETS OPTION 1 – NEGATIVE ACCESSORY OUTPUT- Output acts as a negative
accessory output. # Activates Car Finder Mode.
SETS OPTION 2 – NEGATIVE STARTER OUTPUT- Output acts as a negative starter
output. # Activates Car Finder Mode.
SETS OPTION 3 –AUXILIARY CHANNEL OUTPUT- Press and hold the # button to
activate auxiliary with unlock and disarm pulse. (DEFAULT)
SETS OPTION 1 – DOME LIGHT OUTPUT- The turns on for 30 seconds with unlock
and turns off with lock and ignition on.
SETS OPTION 2 – 2nd UNLOCK- The output will activate when the unlock button is
pressed twice within 3 seconds.
SETS OPTION 3 – TRUNK RELEASE- OUTPUT ACTIVATES WHEN UNLOCK
BUTTON IS PRESSED AND HELD FOR 3 SECONDS (DEFAULT)
72 SERIES
Note- The 1172 can only control features related to the Unlock and Start buttons.
