On-Screen Displays (cont’d)
MP3/Windows Media™ Audio/JPEG Displays
1
Press DVD to put the DVD/VCR in DVD mode.
DVD light will appear on the front of the DVD/VCR.
2
Press DISPLAY repeatedly until the current track or file information
appears.
● Program and Random Playback is available only when DUAL
PLAYBACK is OFF.
● Folder Playback is available only when DUAL PLAYBACK is ON.
3
Press DISPLAY or BACK U to remove the display.
Helpful Hint
• For MP3 files recorded with Variable
Bit Rate (VBR), the elapsed time
displayed on the screen may vary from
the actual elapsed time.
DVDVCR SETUP
INPUT
MENU
REC SPEED MODE
ANGLE SEARCH REPEAT
DISPLAY SUBTITLE ZOOM
TIMER SET
REPEAT
A-B
AUDIO
BACKPAUSESTOP
PLAY
OK
FFW
REW
CLEAR TITLE
DISC
TRACKING
OPEN/CLOSE
12
6
5
4
7
89
0
+10
3
JPEG file name
FOLDER PLAYBACK
RANDOM
PROGRAM
T
MP3 file name
track name
title name
artist name
During Windows Media™ Audio playback
During JPEG playback
or
During MP3 playback
● If Dual Playback is on, MP3 file
name will be displayed after
JPEG file name.
Example: MP3 playback
The following may appear to indicate Repeat Playback.
T: The current track will play repeatedly.
G: Tracks in the current folder (group) will play repeatedly.
A: All tracks will play repeatedly.
only during PROGRAM Playback
or
only during RANDOM Playback
or
only during FOLDER Playback
Current Repeat Setting
Elapsed playing time of
the current track (for
MP3/Windows Media™
Audio only)
TR (track):
Current track number/
total tracks
