EN - 27
27
Satellite Link
You can set the DVD/VCR to start recording whenever it detects a video
signal from the external tuner.
Before you begin :
● Set the clock. Details are on page 20.
● Put a tape in the cassette compartment of the DVD/VCR. Make sure the
tape’s record tab is intact and the tape is long enough to record the
program(s).
● Press VCR so VCR light appears on the front of the DVD/VCR.
● Turn on the external tuner.
● Use the VCR AUDIO and VIDEO IN jacks on the rear (L1) to connect the
DVD/VCR to the external tuner. VCR AUDIO and VIDEO jacks on the
front (L2) cannot read any signal from the external tuner.
● If the external tuner is equipped with some kind of timer function, set it to
output audio/video signals when it comes to the time you want to start
recording and stop when it comes to the time you want to stop recording.
Refer to the tuner’s manual on how to set the timer.
● If the external tuner is not equipped with timer function, leave it on for
Satellite Link Recording.
Instructions continue on the next page.
1
Press SPEED repeatedly until the desired tape speed (SP or
SLP) appears briefly on the screen. Details about tape speed are on
page 58.
2
In stop mode, press SETUP.
3
Press ▲ or ▼to select SATELLITE LINK, then press B.
DVDVCR SETUP
INPUT
MENU
REC SPEED MODE
ANGLE SEARCH REPEAT
DISPLAY SUBTITLE ZOOM
TIMER SET
REPEAT
A-B
AUDIO
BACKPAUSESTOP
PLAY
OK
FFW
REW
CLEAR TITLE
DISC
TRACKING
OPEN/CLOSE
12
6
5
4
7
89
0
+10
3
DIGITAL
AUDIO OUT
COAXIAL
AUDIO
OUT
DVD
L
R
S-VIDEO
OUT
DIGITAL
AUDIO OUT
COAXIAL
AUDIO
OUT
DVD
L
R
S-VIDEO
OUT
L
R
L
R
Y
C
B
/
P
B
AUDIO OUT
DVD/VC R
VCR
VIDEO OUT
AUDIO IN
VIDEO IN
C
R
/
P
R
COMPONENT
VIDEO OUT
DIGITAL
AUDIO OUT
COAXIAL
AUDIO
OUT
DVD
L
R
S-VIDEO
OUT
L1
External tuner
To audio/video
input jacks
Audio/Video Cables
(supplied)
DVD/VCR
SATELLITE LINK
AUTO REPEAT [OFF]
CLOCK SET
LANGUAGE SELECT
TIMER PROGRAMMING
- M E N U -
