46
English
3139 246 14221
Programming recordings
with VCR Plus+
®
System
With the VCR Plus
®
program system, you
only need to enter the PlusCode
programming number as all the
information needed by the DVD recorder
for programming is contained in the
programming number.
1 Turn on the TV power. Select the correct
Video In channel at the TV.
2 Press TIMER on the remote control.
➜ The timer overview appears.
TIMER 11.55 PM
TIMER OVERVIEW
TIMER DETAILS
10:55PM CNBC Weekly
23:45 Disco 12.04
21:00 BBC2 Daily
06:00 PM HBO 16.04
08:00 PM ABC 13.04
Delete New Timer Change
Start time
Stop time
Date
Repeat
Channel
Record Mode Off
12:00 PM
05:05 PM
12:31:2004
Once
CH
VCR Plus+
3 Press the matching color coded button
on the remote control to select
{ VCR Plus+ .}
➜ The VCR Plus+
®
entry screen appears.
TIMER MENU 12.55 PM
VCR Plus+
Clear Store Cancel
4 Use the alphanumeric keypad 0-9 to
enter the PlusCode programming number
for the show you wish to record.
(e.g. : 5-312-4 or 5,312 4, key in ‘53124’.)
➜ This number is up to 8 digits long and
can be found next to the start time of the
TV program in your TV listings magazine.
● To clear the PlusCode programming
number, press the matching color coded
button on the remote control to select
{ Clear .}
● To cancel the VCR Plus+
®
programming,
press the matching color coded button
on the remote control to select
{ Cancel .}
➜ The timer overview appears.
5 Press OK to confirm, then press the
matching color coded button on the
remote control to select { Store .}
➜ The system will store the timer entry
and return to the timer overview screen.
● If the channel number of the TV channel
has not been assigned to the PlusCode
number, you will be asked to enter the
preset number/channel. Follow the
instructions on the TV.
● If the information is missing or not
available, you may be asked to enter more
information. Follow the instructions on
the TV.
● If you want to make changes, use
3 4 1 2 to select the appropriate entry
field. If required, make changes using 3 4
or the alphanumeric keypad 0-9.
6 To exit, press TIMER.
7 Insert a DVD+R(W).
8 Press STANDBY-ON to switch off the
DVD recorder.
➜ The DVD recorder must be in standby
mode in order for the timer recording to
occur. If not, a warning message will
appear ten minutes before the recording
starts.
➜ If you ignore the warning message, the
DVD recorder will switch to standby
mode automatically before the
programmed recording begin.
➜ The '
TIMER’ icon will light up on the
display panel if a timer recording is set.
Timer Recording (cont’d)
TIPS: To play a DVD+R on other DVD players, see “Finalizing disc (DVD+R).”
During timer recording, press STANDBY-ON will stop recording.
