Product Information
Product Features • Technical Specifications • Automatic Power Saving • Physical Specification • Pin
Assignment • Product Views
Product Features
Model Regulation Color
201B40 TCO'03 Gray
201B4:
● 21-inch (20.0" VIS) color monitor with excellent front of screen performance for use with MACs, PCs or
Workstations
● Autoscan covers horizontal frequencies up to 115 kHz offering a maximum resolution of 2048 x 1536 with
flicker free display of 1600 x 1200 at up to 85 Hz
● Flat square Super High Contrast CRT with high-resolution 0.25 mm pitch (0.21 hdp)
● Auto Calibrate extends the useful life of the monitor by automatically adjusting color and luminance to
original values.
● XSD-Xtra Space Design for large screen display in a small footprint: World's shortest 21-inch monitor
with maximum depth of only 467 mm/18.4"
● sRGB for true on screen color representation.
● FCC, CE (in selected countries only) and ISO9241, ISO14001 certified
RETURN TO TOP OF THE PAGE
Technical Specifications*
CRT
• Size and
deflection
21 inch / 51 cm ; 90° deflection angle
• Dot pitch /
Grille pitch
0.25 mm
• Horizontal pitch 0.21 mm
• Tube type
Shadow mask, flat square, super high contrast, anti-glare, anti-static, anti
reflection
