ON Active Yes Yes
Typical
104W
0 % Green
OFF Blanked No No < 1W 99% Yellow
This monitor is ENERGY STAR
®
compliant. As an ENERGY STAR
®
Partner, PHILIPS has
determined that this product meets the ENERGY STAR
®
guidelines for energy efficiency.
RETURN TO TOP OF THE PAGE
Physical Specifications
• Dimensions
19.0" x 18.7" x 18.4" / 482 x 476 x 467 mm (including base)
19.0" x 17.2" x 18.4" / 482 x 437 x 467 mm (excluding base)
• Weight 23.5 kg
• Power supply 100-240VAC, 60-50Hz
• Temperature
(operating)
0° to 35°C / 32° to 95°F
• Temperature (storage) -25° to +65°C / -13° to +149°F
• Relative humidity 5% to 95%
* Resolution 1280 x 1024, standard size, contrast max., brightness 50%, 9300°, full white pattern.
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable (IBM systems):
