Front of your TVCR Back of your TVCR
STANDBY/ON
VIDEO AUDIO
P
✄
STANDBY/ON: To switch off or on, interrupt menu function.
Volume: In connection with the button to adjust the volume.
Programme number minus: previous programme number
Programme number plus: next programme number
Record: To record the programme currently selected.
Playback: To play a recorded cassette.
Pause/Stop, eject cassette:To stop the tape; If this key is depressed while in
STOP, the cassette is then ejected from the machine.
When tape playback is stopped, press to fast forward the tape at hight speed.
When tape playback is stoped, press to rewind the tape at hight speed.
Sockets on the front:
White socket / input socket:
To connect a camcorder or a video game
machine (audio).
Yellow socket / input socket: To connect a camcorder or a video game
machine (video).
Small socket / socket for headphones: To connect headphones.
Aerial input socket: To connect the aerial cable.
Scart socket :To connect a satellite receiver, decoder, video recorder, etc
Power switch: To switch the TVCR off.
Caution: If you switch off using the power switch, TIMER-recordings are impossible!
The control lights at the front of machine
STANDBY Standby light:lights up when the TVCR has been switched on by means
of the main switch.
RECORD Recording light: lights up during recording.
FAST blink: RECORDING PAUSE;TIMER RECORDING NOT STAND-BY.
SLOW blink:TIMER RECORDING is stored in a timer block.
EXT1/AV1
VIDEO
AUDIO
0
1
C
/
AA
B
I
P+
P-
–+
55
yy
EN
