Table 21 describes the information fields for the show ports info atm
all command.
Table 21 Information fields for the show ports info atm all command
Field Description
PORT NUM Port number.
MDA DESCRIPTION This field describes the MDA:
• Quad OC-3c SM — quad port OC-3c single-mode fiber
• Quad OC-3c MM — quad port OC-3c multimode fiber
• OC-12c SM — single port OC-12c single-mode fiber
• OC-12c MM — single port OC-12c multimode fiber
SCRAMBLE ENABLE Parameter that enables/disables the scrambling option.
FRAMING MODE Indicates the framing for the port, either:
• sonet, which means the Synchronous Optical Network
format, the standard format in North America.
• sdh, which means the Synchronous Digital Hierarchy
clock format, the standard format in Europe.
MAX-BITS VPI For OC-3c, 11 bits split between NumVpiBits and
NumVciBits. NumVpiBits cannot exceed 6 bits for OC-3c.
For OC-12c, 13 bits split between NumVpiBits and
NumVciBits. NumVpiBits cannot exceed 8 bits for OC-12c.
MAX-BITS VCI This field is read only. It takes remaining bits from
NumVpiBits. For example, if NumVpiBits is 3 for OC-3c,
then NumVciBits is 8.
CLOCK SOURCE Indicates whether the Clock Source is either:
• line
• internal
LOOPBACK MODE Indicates the loopback mode::
• off
• internal
• external
ADMIN STATE Indicates the Admin State of the port, either:
• up
• down
STATUS Indicates the status of the port, either:
• up
• down
PVC VPI.VCI Permanent virtual circuit and the associated vpi and vci
numeric identifiers.
