Chapter 4 Managing the Passport 8672ATM Module with Device Manager 49
Using the Passport 8672ATM Module
• Getting Started with the Passport 8000 Series Management Software
• Reference for the Passport 8000 Series Management Software Routing
Operations
• Reference for the Passport 8000 Series Management Software Switching
Operations
The following sections describe the Device Manager features that are specific to
the Passport 8672ATM Module:
• “Installing Device Manager,” next
• “Configuring ATM using Device Manager” on page 51
• “Displaying statistics using Device Manager” on page 71
• “Testing using Device Manager” on page 71
Device Manager access and passwords
For a complete discussion of Passport access levels and passwords, refer to
Reference for the Passport 8000 Series Management Software Switching
Operations.
Installing Device Manager
To install Device Manager:
1 Download the Device Manager software from the CD.
2 Double-click the icon and follow the instructions on the screen.
When you launch Device Manager, a graphical image of the Passport 8600
chassis with the Passport 8672ATM Module installed is displayed (Figure 11).
