Function Page
å ESC OFF warning
lamp
473
j Parking space indicator
lamp 350
é Recuperative Brake
System (RBS) warning
lamp, S 400 HYBRID only
2
Green or yellow READY
indicator lamp for the
HYBRID system, S 400
HYBRID only
2
A
Parktronic/Parking
Guidance warning indicator
for right front area 349
B
Transmission position/
range indicator 321
C
Tachometer with:
; Engine malfunction
indicator lamp
496
Function Page
D
Program mode indicator 322
E
Main menus for instrument
cluster control system 222
F
Outside temperature 327
G
Display with:
Additional speedometer 235
_ Adaptive Highbeam
Assist indicator lamp
301
à Lane Keeping
Assistance indicator lamp
362
À Attention Assist
indicator lamp
355
Ä PRE-SAFE
®
Brake
indicator lamp
232
or
HOLD function indicator
lamp 342
2
See separate HYBRID Supplemental Operating Instructions.
Instrument cluster
33
At a glance
