display and are based on conditions or
system status the vehicle’s system has
recorded.
The vehicle status message memory function
only appears if there are any messages
stored.
G
Warning!
Malfunction and warning messages are only
indicated for certain systems and are
intentionally not very detailed. The
malfunction and warning messages are
simply a reminder with respect to the
operation of certain systems. They do not
replace the owner’s and/or driver’s
responsibility to maintain the vehicle’s
operating safety. Have all required
maintenance and safety checks performed on
the vehicle. Bring the vehicle to an authorized
Mercedes-Benz Center to address the
malfunction and warning messages.
X
Press button = or ; to select the
Service menu.
If conditions have occurred causing status
messages to be recorded, the number of
messages appears in the multifunction
display: 2 Messages.
X
Press button : or 9 to select the
Messages function.
X
Press button a to confirm.
For malfunction and warning messages,
see “Vehicle status messages in the
multifunction display” (Y page 452).
X
Use button : or 9 to scroll through
the messages.
If you turn the SmartKey in the starter switch
to position 0 and then back to position 2, all
messages will be deleted from the message
memory.
Settings menu
In the Settings menu the following functions
are available:
R
Switching daytime running lamp mode on
or off (USA only) (Y page 234)
R
Setting Adaptive Highbeam Assist
(Y page 235)
R
Showing or hiding additional speedometer
(Y page 235)
R
Selecting speedometer display mode
(Y page 235)
R
Activating/deactivating the seat belt
adjustment function (Y page 236)
R
Switching the radar sensors on or off
(Y page 236)
Switching daytime running lamp mode
on or off (USA only)
X
Press button = or ; to select the
Settings menu.
X
Press button : or 9 to select the
Day Running Lamps function.
X
Press button a.
234
Instrument cluster control system
Control systems
