A-2 Specifications
Specifications
Dimensions (Assembled) Height:
Depth without tables:
Depth with tables:
Width:
63 inches (160 cm)
49 inches (124 cm)
121inches (307 cm)
179 inches (454 cm)
Weight (Assembled) Printer without tables:
Tables only:
1675 pounds (760 kg)
150 pounds (68 kg)
Operating Conditions Temperature: 68–85° F (20–30° C)
Relative Humidity: 20–80%, non-condensing
Storage Conditions Temperature: -30–120° F (-34–49° C)
Relative Humidity: 10–80%, non-condensing
Agency Compliance Safety: CE, UL, c-UL
Emissions: FCC-A, CE
Immunity: CE
Electrical Power
Power used: 200-240 VAC, three phase (3
φ), 50/60 Hz, 16 Amps maxi-
mum
Required electrical circuit:
North America/Japan
200-240 VAC, 20 Amps, 3φ, with NEMA L21-20R locking wall receptacle
Europe
200-250 VAC, 16 Amps, 3
φ, with 5-pin IEC 60309 wall receptacle
NEMA L21-20R receptacle
4-pole 5-wire grounding
20A 3-phase
locking
Line
Ground
Neutral
IEC 60309 receptacle
5-pin
16A 3-phase
200-240 VAC
Neutral
Line
Ground
