Map Screen Features
12
MAX983HD
English
Indicators on the scrolled map
Indicators are displayed after scrolling the map. During scrolling, only the scroll cursor is displayed on
the map.
1 [Back] key
Returns to the map of current location.
2 [OK] key
Displays the Location menu. You can set the
location under the cursor as the destination or
store this location. ➜ “Location menu (Menu on
scrolled map)” (P. 9)
3 Scroll cursor
Displayed when scrolling the map.
4 Latitude/longitude information
Displays the latitude/longitude information of the
location under the cursor. Whether this is
displayed or not can be set. ➜ “Map Scrolling
Information” (P. 47)
5 Location information
When moving the cursor on a Stored Location,
destination, or waypoint, the place name will be
displayed.
If the TMC icon is put together to the cursor, the
TMC information is displayed.
3 4
5
1
2
