Cisco MDS 9216 Switch Hardware Installation Guide
78-16165-01
APPENDIX
C
Cable and Port Specifications
This appendix provides the following information:
• Cables and Adapters Provided, page C-1
• Console Port, page C-2
• COM1 Port, page C-4
• MGMT 10/100 Ethernet Port, page C-6
• SFP Transceiver Specifications, page C-8
Cables and Adapters Provided
The Cisco MDS 9216 Switch accessory kit includes the following items:
• RJ-45 to RJ-45 rollover cable
• RJ-45 to DB-9 female DTE adapter (color-coded green and labeled “FOR
DS-C9216-K9 ONLY”; for use with the COM1 port)
• RJ-45 to DB-9 female DTE adapter (labeled “Terminal”; for use with the
console port)
• RJ-45 to DB-25 female DTE adapter (labeled “Terminal”)
• RJ-45 to DB-25 male DCE adapter (labeled “Modem”)
Note Additional cables and adapters can be ordered from your customer service
representative.
