46
Jack PC Hardware User Manual - Training Department
Version 0506
C. Performance Data
1
C1. Electromagnetic Compatibility
Systems marked with the symbol “CE” indicate compliance to the EMC Directive and the Low Voltage Directive of the
European Union.
C2. System Configuration
The Energy Consumption and Declared Noise Emissions data is based on a device running the highest resolution
and color depth setting, in 100BaseT full duplex network with ICA session presenting graphic intensive screen saver.
Standard USB optical mouse and USB keyboard connected.
1
This document is informational only and reflects laboratory performance. Your product may perform differently, depending on the
software, components and peripherals you operate. Accordingly, the customer should not rely upon this information in making
decisions about electrical tolerances or otherwise. No warranty as to accuracy or completeness is expressed or implied. The
information in this document may change without notice; please note the revision number on the last page.
D. Energy consumption
Service Level
Energy
Consumptio
n (Wattage)
Heat
Dissipation
(BTU/hr)
Description of Service Level
Energy Save
Requirements Meets EU
ECO label (2001/686/EC
and 2001/687/EC)
Yes / No / N/A
*Maximum
6.00 13.6
The system is running programs to
maximize the power consumption
N/A
Minimum
2.8 8.9
The system is in a waiting mode, such as
at the local desktop no session is running
N/A
ACPI S3
0.6 2 The system is in a low-power/sleep mode
Yes
Off (standby)
0.6 2
The system is turned off but is still
connected to its power source
Yes
Energy consumption is tested at 230 Volts / 50 Hz. Heat dissipation is calculated based on the measured watts,
assuming the service level is attained for one hour. Off data is not meant to show compliance to US Executive Order
13221.
*Maximum Energy Consumption results are based solely upon the testing of the System Configuration listed above.
E. Declared Noise Emissions in accordance with ISO 9296
Service Level
Sound Power
(L
WAd
, bels) (1 bel=10 decibels, re 10
-12
Watts)
Sound Pressure Operator
Position
(L
pAm
, decibels) (re 2x10
-5
Pa)
Inside active ICA
session
0.00 0.00
Idle – local desktop 0.00 0.00
