warranty and may damage the battery or cause a fire hazard. Do
not use the XLR8R charger to charge anything other than the
XLR8R battery. Stop using the charger if its wires become worn or
damaged in any way. Replace the charger with a new XLR8R
battery charger.
To operate the XLR8R motor
1. Turn the XLR8R's power switch to the On position.
2. Grasp the scooter's handlebars firmly.
3. Position one foot on the scooter's deck.
4. Pull the XLR8R trigger switch. DO NOT USE THE BRAKE
AND TRIGGER AT THE SAME TIME.
5. Using your other foot, give a strong push so as to propel the
scooter at a rate of 3 mph.
Note that the XLR8R motor will not engage until the scooter is
traveling 3 mph. This approach extends battery run time, prolongs
motor life, and enables children to learn to start off on a XLR8R
powered scooter more easily.
Note: If the XLR8R does not turn on,
1. Check to see that the battery is charged
2. Check to make sure the battery is connected inside the case.
3. Check to make sure the power switch is in the on position.
WARNING: Do not allow the XLR8R to “run on” if the drive
system slips on the wheel and forward speed has slowed or
stopped. Release the trigger before you come to a stop when
slowiing down. DO NOT USE THE BRAKE AT THE SAME TIME
AS THE TRIGGER.
7
6
Charger port and on/off switch
The battery must be fully charged before initial use.
Initial charging time on the XLR8R battery may be a few minutes
to up to 8 hours. Only charge the battery indoors in a dry location.
WARNING: The battery charger is not intended for use by
children. The XLR8R battery should always be charged by an
adult. Children should be kept away from the battery and charger
during the charging process. Only use XLR8R-brand battery
packs. Do not disassemble, incinerate or dispose of the battery in
fire. Dispose of used battery properly. There is a danger of
explosion if battery is incorrectly replaced. The battery may
present a risk of fire or chemical burn if mistreated.
CAUTION: Do not charge the XLR8R battery in wet
conditions. Only use the battery charger that accompanies your
XLR8R Motor. Use of any other charger voids the XLR8R
