302
Practical hints
Where will I find ...?
Operational position
̈ Turn crank handle clockwise until it
engages (operational position).
Before storing the vehicle jack in its
compartment:
ț It should be fully collapsed.
ț The handle must be folded in (storage
position).
Minispare wheel
The Minispare wheel is located in the
storage compartment underneath the
cargo compartment floor.
Removing the Minispare wheel
̈ Lift up cargo compartment floor cover.
1 Retaining screw
2 Storage well casing
̈ Loosen retaining screw 1 in the
middle of storage well casing 2.
̈ Remove storage well casing 2.
3 Arrow
4 Minispare wheel
5 Luggage bowl
̈ Remove luggage bowl 5.
̈ Remove Minispare wheel 4.
Storing the Minispare wheel
̈ Place Minispare wheel 4 in wheel
well.
̈ Place luggage bowl 5 over the
Minispare wheel.
Make sure arrow 3 on the luggage
bowl 5 points in the direction of
travel.
