Controls in detail
Loading
Storage compartment under cargo
compartment floor
To open cargo compartment floor
̈ Press handle 1 on the recess.
̈ Lift compartment cover.
To close cargo compartment floor
̈ Lower the cover and lock by applying
light pressure to handle 1.
Retractable luggage cover and
partition net
The twin-reel roller blind comprises a lug-
gage cover and a partition net. It is mount-
ed on the backrest of the rear seat and can
also be used with backrest folded down.
Partition net
Partition net with rear seats folded up
1 Tab
2 Eyelets on roof
̈ Pull out upper blind (safety net) by
tabs 1.
̈ Engage it into eyelets on the roof 2.
i
The compartment can be used to store
small, light or flat objects.
Warning! G
If items are stored in the compartment,
make sure compartment is securely closed.
In an accident, during hard braking or sud-
den maneuvers, they could be thrown
around inside the vehicle, and cause injury
to vehicle occupants.
Warning! G
To help avoid personal injury during a colli-
sion or sudden maneuver, always use parti-
tion net when transporting cargo.
