Black plate (265,1)
CAUTION
l
Don't bend or discard the stiffeners.
You need to use them again.
l
If the metal stiffeners are switched,
the blade's wiping efficiency could
be reduced.
So don't use the driver's side metal
stiffeners on the passenger's side, or
vice versa.
l
Be sure to reinstall the met al
stiffeners in the new blade rubber so
that the curve is the same as it was in
the old blade rubber.
4. Carefully insert the new blade rubber.
Then install the blade assembly in the
reverse order of removal.
Tab
NOTE
Install the blade so that the tabs are
toward the bottom of the wiper arm.
qReplacing Rear Window Wiper
Blade (Hatchback/Wagon)
When the wiper no longer cleans well, the
blade is probably worn or cracked.
Replace it.
CAUTION
To prevent damage to the wiper arm
and other components, don't move the
wiper by hand.
(Hatchback)
1. Raise the wiper arm and turn the blade
assembly to expose the plastic locking
clip.
Compress the clip and slide the
assembly downward; then lift it off the
arm.
Plastic locking clip
Push
CAUTION
To prevent damage to the rear window,
don't let the wiper arm fall on it.
Maintenance andCare
Owner Maintenance
8-23
