Black plate (313,1)
With Non-LED bulb
1. Remove the cover.
Left side
Right side
2. Turn the socket and bulb assembly
counterclockwise and remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
NOTE
To replace the bulb, contact an Authorized
Mazda Dealer.
Rear turn signal lights (4 Door)
1. Pull the center of each plastic retainer,
and then remove the retainers and the
trunk end trim.
Removal
Installation
2. Pull the center of each plastic retainer
and remove the retainers, and then
partially open the trunk side trim.
Removal
Installation
3. Turn the socket and bulb assembly
counterclockwise and remove it.
Maintenance andCare
Owner Maintenance
8-45
Mazda3_8X41-EA-07F_Edition1 Page313
Wednesday, April 25 2007 1:7 PM
Form No.8X41-EA-07F
