91
WideSide® Sensitivity
(Advanced: with WideSide® transducer)
WideSide® Sensitivity adjusts the sensitivity of the WideSide® beam.
Increasing the sensitivity will display additional weak returns and decreasing
the sensitivity will display few weak returns. A WideSide® transducer must be
attached to the Fishing System. The WideSide® Sensitivity menu choice is
available when Transducer Select is set to WideSide® (see Sonar Menu Tab:
Transducer Select) and User Mode is set to Advanced (see Setup Menu Tab:
User Mode).
NOTE: The WideSide® Sensitivity requires the purchase of the WideSide® transducer. You can
visit our website at www.humminbird.com to order this accessory online or contact our
Customer Resource Center at 1-800-633-1468.
NOTE: WideSide® Sensitivity is particularly useful for adjusting the sensitivity of the 455 kHz
sonar returns in the WideSide® View. The 455 kHz sensitivity can be adjusted without affecting
the sensitivity of the other sonar frequencies.
To change the WideSide® Sensitivity setting:
1. Make sure you have selected WideSide® Transducer and Advanced
Mode and that the WideSide® transducer is connected, then highlight
WideSide® Sensitivity on the Sonar Main Menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the
WideSide® Sensitivity. (-10 to +10, Default = 0)
