SKU 65063 For technical questions, please call 1-800-444-3353. Page 6
The smaller the gauge number of the 3.
wire, the greater the capacity of the
cord. For example, a 14 gauge cord
can carry a higher current than a 16
gauge cord. (See Table A.)
When using more than one exten-4.
sion cord to make up the total length,
make sure each cord contains at
least the minimum wire size required.
(See Table A.)
If you are using one extension cord 5.
for more than one tool, add the
nameplate amperes and use the sum
to determine the required minimum
cord size. (See Table A.)
If you are using an extension cord 6.
outdoors, make sure it is marked with
the sufx “W-A” (“W” in Canada) to
indicate it is acceptable for outdoor
use.
Make sure the extension cord is prop-7.
erly wired and in good electrical con-
dition. Always replace a damaged
extension cord or have it repaired by
a qualied electrician before using it.
SYMBOLOGY
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
V~
Volts Alternating Current
A
Amperes
n
0
xxxx/min.
No Load Revolutions per Minute
(RPM)
PRODUCT SPECIFICATIONS
Product Applications
Designed to charge most
cell phones. Also adapts
to MP3, M4, PDA’s, digital
camera, etc.
AC/DC Adapter Input 110 V~ / 60 Hz
AC/DC Adapter Output 5 VDC, 500mA
AC/DC Cord Type 22 AWG
AC/DC Plug Type 2-Prong, Grounded
Lithium Battery Capacity 1000 mAH
Unit Charging Capacity Approximately 4~6 Hours
Solar Power Output 80 mA/120 mA
Solar Charger Charge Time 4~6 Hours
AC/DC Charge Time 1~2 Hours
Charge Time from Charger to
Mobile cell phone
60~90 Minutes
L.E.D. Functions
Red Charging:
(Turns to Green on Full
Charge).
Multi-Flashing:
(Indicates DC Power to
Charger).
Flashlight:
(Push Button on Side)
Accessories Plug Adapters (Qty. 5)
RECOMMENDED MINIMUM WIRE
GAUGE FOR EXTENSION CORDS*
(110/240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25’
50’
75’
100’
150’
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
