MENU TREE
AP-2
Marks menu
[MENU] key
(MARKS
selected from
MENU MODE)
RANGE RINGS (1/4R , 1/2R, OFF)
BEARING SCALE (ON, OFF)
CURRENT VECTOR (ON, OFF)
CURRENT DIR (TO, FROM)
SHIP’S TRACK (10R, 5R, OFF)
COURSE (32CMPS, 360TRUE)
HEADING (32CMPS, 360TRUE, OFF)
CURRENT DATA (32CMPS, 360TRUE, 180 , 360 )
EVENT/FISH (32CMPS, 360TRUE, 180 , 360 )
OTHER MARKS ( 180 , 360 )
POSITION DATA (L/L, TD)
System menu
[MENU] key
(SYSTEM
selected from
MENU MODE)
DIMMER (0-10, 10)
DISP SELECT (TEMP, CURRENT)
HEADING ADJ (0-359 , 0 )
AUTO RETRACT (OFF, 5-16 kt)
SPEED MESSAGE (ON, OFF)
EXT KP SYNC (OFF, ON)
AUTO TRAIN SPD (LOW, HIGH)
AUTO TILT SPD (LOW, HIGH)
UNIT (METERS, FEET, FATHOMS, PA/BRA)
SHIP’S SPD/BR (LOG/GYRO, CURRENT, NAV DATA, GYRO+NAV)
LOG PULSE (200, 400)
PORT1 BAUDRATE (19200, 9600, 4800, 2400)
PORT1 FORMAT (NMEA, CIF)
PORT2 BAUDRATE (19200, 9600, 4800, 2400)
PORT2 FORMAT (NMEA, CIF)
NAV DATA (GPS, LC, DR, ALL)
COMBI SCALE (RIGHT, LEFT)
SUB TEXT INDI (OFF, ON)
LANGUAGE (ENGLISH, Others)
TEST (SINGLE, CONTI, PANEL, COLOR, PATTERN, SIO, ECHO-1, ECHO-2, ECHO-3*, ECHO-4*)
SET TO DEFAULT :EXECUTE
* = CSH-5L only
