K8285a-0920
8
Children can be harmed by small parts,
sharp edges and sharp points in the vehicle's
unassembled state, or by electrical items.
Care should be taken in unpacking and
assembly of the vehicle. Children should
not handle parts, including the battery,
or help in assembly of the vehicle.
WARNING
• Fit the front grille to the vehicle, as shown.
• Be sure the tabs on both ends of the grille fit into the groove in
each fender.
Charger
Connector
1
Front Grille
ASSEMBLY
A
B
• Plug the charger connector into the battery
A
.
• Plug the charger into a standard wall outlet. The power indicator
lights
B
.
Notes:
- If power flow to the wall outlet is controlled by a switch, make sure
the switch is “ON”.
- Use the charger only in a wall outlet. Do not plug the charger into
a ceiling outlet.
- The power indicator on the charger does not indicate the charge
status of your battery. The power indicator allows you to see
that there is power from the wall outlet.
• Before first-time use, charge the battery for at least 18 hours.
Never charge the battery longer than 30 hours.
• Recharge the battery for at least 14 hours after each use of your
vehicle. Do not charge the battery longer than 30 hours.
• Once the battery is charged, disconnect the charger connector from
the battery. Unplug the charger from the wall outlet. The battery is
now ready to be installed in your vehicle. Please see the Battery
Installation section on page 18 for detailed instructions on installing
your battery. If your battery is already installed in your vehicle, simply
re-connect the motor harness connector to the battery.
Power
Indicator
Tab
Slot
