K8285a-0920
14
BACK VIEW
• Insert the "T" fastener end of a short seat belt strap through the
slot near the outer edge of the seat. Make sure the fastener side
of the seat belt faces inward.
Note: You will pull only one T-Loop through the slot.
• Repeat this procedure to assemble the other short seat belt strap.
• Insert each fastener end of the long seat belt strap through the
slots in the center of the seat. Make sure the fasteners face the
outer edge of the seat.
• Pull each side of the long seat belt strap evenly through the slots.
Make sure to pull each T-loop through a slot.
• Turn the vehicle upright.
• Insert both tabs on the back edge of the seat into the slots inside
the bed.
22
Short Seat Belts
Long Seat Belt
• Insert two screws through the back of the seat and into the vehicle.
Tighten the screws.
24
23
Slots
Seat
• Align the tabs on a hubcap with the slots in a rear wheel. “Snap”
a hubcap into the center of the rear wheel.
Hint: If the hubcap does not "snap" into place, you may not have
assembled the wire clip properly. Remove the wire clip and refer
back to step 18.
• Repeat steps 17 - 21 to assemble the other rear wheel, wire clip
and hubcap.
21
Hubcap
Screws
