Quick Reference Card
1
I
EZ-Programming Details ̈
Factory Default Settings
To reset Passport to its original factory
settings, press and hold the “CITY” and
“MUTE” buttons while turning the power
on. Passport’s display will provide a
“Reset” message, accompanied by an
audible alert, acknowledging the reset.
Passport SR7 Quick Reference Card
̄ Remove card along perforations ̄
̄ Remove card along perforations ̄
Congratulations and Important Warning
Congratulations
Your new Passport SR7 is the most
advanced custom-installed radar/laser
detector available.
The Passport SR7 includes long-range
X, K, and SuperWide Ka radar capability,
improved Digital Signal Processing for
superior range and reduced false alarms, our
patented Mute and AutoMute, audible and
visual band alerts, and all the performance
you’d expect from Escort.
In addition, your new Passport SR7
introduces a new level of Radar/Laser
defense including:
• Supercharged radar performance, for
superior K, and Ka-band sensitivity
• Advanced EZ-Programming lets you
instantly set up to 9 customized features
• Exclusive AutoSensitivity
™
mode
drastically reduces false alarms, plus
Highway and City settings
• Ultra-bright alphanumeric display uses 280
LEDs for crystal clear information
• Exclusive ExpertMeter
™
tracks and
displays up to 8 radar signals
• New SpecDisplay provides numeric
frequency for any radar signal
• Detects and decodes up to 64 Safety
Warning Systems signals
• Exclusive vertical display option provides
maximum installation flexibility
• Standard remote mute button provides
one-touch mute, and volume adjustment
• Optional Laser Shifter
™
ZR3 compatible
If you’ve used a radar detector before, a
review of the Quick Reference Guide on
page 4, and the EZ-Programming information
on pages 10 and 11 will briefly explain the
new features.
If this is your first detector, please read
the manual in detail to get the most out of
your new Passport’s performance and
features.
Please drive safely.
IMPORTANT INSTALLATION WARNING
Your new Passport must be installed by a
professional. Car Audio specialists and many
car dealers can install Passport for you.
Attempting to install the Passport SR7
without expertise in automotive electronic
installations can cause personal injury
during the installation, or can damage your
Passport or your vehicle. If your vehicle is
damaged during installation, its safety
systems may be compromised, which could
cause personal injury or property damage.
FCC Note:
Modifications not expressly approved by
the manufacturer could void the user’s FCC
granted authority to operate the equipment.
An example
For example, here is how you would turn
Passport’s AutoMute feature off.
1 Enter the Program Mode by holding
both the CITY and MUTE buttons down for
2 seconds. Passport will beep twice and
display Program.
2 Press and hold the REVIEW button.
Passport will scroll through the categories,
starting with Pilot Light (Pilot), then
Power-on sequence (PwrOn), then Signal
strength meter (Meter), and then
AutoMute (aMute).
3 Release the REVIEW button when
Passport shows the AutoMute item. Since
the factory setting is for AutoMute to be
on, Passport will display aMute ON.
(If you accidentally don't release the
Review button in time, and Passport goes
to the next category, hold the Review
button down again, and after Passport
scrolls through all categories, it will begin
again at the top of the list.)
4 Press the CHANGE button to change
from aMute ON to aMute OFF.
5 To complete the Programming, simply
wait 8 seconds without pressing any button.
Passport will display Complete, beep 4
times, and return to normal operation.
There are 9 user-selectable options so you
can customize your Passport SR7 for your
own preferences.
The buttons labeled CITY and MUTE are
also used to enter the Program Mode,
REVIEW your current program settings, and
to CHANGE any settings as desired. The
words PROGRAM, REVIEW, and CHANGE
are located on the front of the display, and
are highlighted in gold graphics.
How to use EZ-Programming
1 To enter Program Mode, press and
hold both buttons down for 2 seconds.
(The unit will beep twice, and will display
the word “Program”).
2 Then press the REVIEW button to
review the current settings. (You can
either tap the button to change from item
to item, or hold the button to scroll through
the items).
3 Press the CHANGE button to change
any setting. (You can either tap the button
to change from setting to setting, or hold
the button to scroll through all the options).
4 To leave Program Mode, simply wait
8 seconds without pressing any button.
(The unit will display Complete, beep 4
times, and return to normal operation).
